GST-115
GOSUNM
Product Description
quipment Configuration
S/N | Item | Brand | Origin | QTY |
1 | Step motor | Leadshine | China | 1 |
2 | Earth leakage breaker | Chint/Schneider | China/France | 1 |
3 | Conveyor motor | Leadshine | China | 1 |
4 | Photoelectric sensors | OMRON/Schneider | Japan/France | 1 |
5 | Sensors | Panasonic | Japan | 1 |
6 | PLC | Mitsubishi | Japan | 1 |
7 | Switch | Meanwell | China | 1 |
8 | Touch screen | WECON | China | 1 |
9 | Relay | Schneider | France | 1 |
Technical parameters
Model | GS-T115 |
Voltage | AC220V, 50Hz |
Machine Dimension | Length 2100(L)*650(W)*1500(H)(mm) |
Conveyor line height from the ground | 700mm |
Labeling accuracy | ±1mm |
Labeling speed | 10-350pcs/min |
Applicable product range | Length 25mm～φ200mm Width 10-200mm Thickness:0.05-2mm |
Compatible label size | Length: 5-300mm Width: 10-170mm (including backing width) |
Maximum label diameter supply | 300mm |
Roll label inner diameter | 76mm |
Working environment | 10~40℃ |
Relative Humidity | 15-85% |
Air pressure | Non |
Product Features
Equipment Features
1. pagination technology adopts 2-stage friction principle, silicone soft material is non-abrasive to products, wide range of thickness compatibility, suitable for thin products such as cards, PE tapes and other automatic dividing function.
2. change the traditional power control method, the labeling position is still in the original position after the speed change in the labeling process, which makes labeling debugging very simple.
3. Using Japan brand PLC, German label sensor, the equipment in the operation process of higher stability
4. Full body stainless steel design, more beautiful appearance, occupy less space, easier to use
5. The new design of label winding, foolproof operation, traction mechanism operation is more humane
Aftersales Service
1. One-year machine warranty, lifetime maintenance service.
2. Experienced engineers provide fast and professional 24 hours online guidance.
3. Provide complete teaching videos and instruction manual, easy to operate and maintain. The video of the operation is stored on a USB shipped with the machine
