Automatic Desktop Flat Surface Labeling Machine

Small size, light weight, easy to use and move.
Suitable for top labeling.
Labeling speed: 50~150pcs/min

Technical parameters
Weight: about 70kg
Power supply: 220V 50Hz
Labeling accuracy: ±1 mm
Applicable label size: lengh 10~150mm, width 10~150mm
Applicable product size: lengh 30~250mm, width 30~195mm
Maximum label requirement:outer dia.280mm,inner dia. 76mm
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • GST-113T

Product Features

Products Application

Products Application


Basic machine introduction

Basic machine introduction


Machine workflow

machine workflow

roll directions


Suitable Label Size For The Machine

suitable-label-size-for-the-machine


Advantage

advantages1


1. The height and width of the protective fence can be adjusted, which can effectively prevent the product from shifting and falling during the labeling process. It makes labeling more accurate,  smooth and stable.

advantages2


2. Label out positioning photoelectric:

High-sensitivity label out positioning photoelectricity can precisely control the label  out position.

advantages3

3. Labelling positioning photoelectric:

Adjustable high sensitivity photoelectric, can be used for different material products detection positioning labelling.

advantages4



4. Vertical and horizontal

adjustment mechanism

The labeling position can be adjusted from up, down side and left, and right side. The adjustment mechanism can apply to many different sizes and specifications of label. It has a window to display the current value and is very convenient for quick adjustment and switching between products of various specifications.

advantages5


Machine detail

button detail


细节展示


Product Description

Standard equipment configuration

a. 1 set automatic desktop flat surface labeling machine


List of main components

a. stepper motor
b. stepper drive
c. Conveyor motor
d. HMI (Touch screen)
e. Sensor (check label)
f. Sensor (check product)
g. programmable control (PLC)
h. machine frame


Self-adhesive label parameters

Roll label in the labeling machine work the entire process, including label delivery, positioning, out of the label, paste and backing paper re-roll, to successfully complete the labeling process, the overall label has the following requirements:

Label spacing: 3-4mm ± 0.2mm, the upper and lower edge of the label and the bottom of the backing paper spacing: 2mm

Surface material: basic grammage 78 g/m2 plus or minus 10%,Thickness: 0.064mm plus or minus 10%

Backing paper: Basic weight 61g/m2 plus or minus 10% Thickness: 0.055mm plus or minus 10%

Consistent release force, uniform thickness, a certain tensile strength, translucent Grassian base paper is generally between 60-80 g, fiber density tightness flatness to be good, not easy to break when labeling, the overall translucency to be consistent, the sensor correctly identify the location of the label.

Tensile force: machine direction: 16kg/25mm    Horizontal direction: 7kg/25mm

Tear resistance: machine direction: 25g / sheet    Crosswise: 31g/sheet


Before labeling to eliminate the static electricity in the roll label, so that the label is firm out of the label, from the backing paper, because static electricity will cause labeling when not out of the label or the labeling inaccuracy phenomenon, die-cutting to avoid cutting through the backing paper and not out of the label and torn backing paper phenomenon.


Aftersales Service

1.    One-year machine warranty, lifetime maintenance service.

2.    Experienced engineers provide fast and professional 24 hours online guidance.

3.    Provide complete teaching videos and instruction manual, easy to operate and maintain. The video of the operation is stored on a USB shipped with the machine


Product packaging

product packaging
