Flat Surface Labeling Head For Production Line

Weight: about 30kg
Power supply: 220V, 50Hz
Labeling speed: about 35m/min
Labeling accuracy: ±1 mm
Applicable label size: lengh 10~150mm; width 10~150mm
Applicable product size: lengh 30~195mm width 30~250mm
Maximum label requirement:outer diameter 280mm,inner dia 76mm
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • GST-511

Parameter

Standard equipment configuration

a. Stepper motor

b. Stepper Drive

c. Touch Screen

d. Sensor (check label)

e. Sensor (check product)

g. programmable control (PLC)

h. machine frame


Self-adhesive label parameters

Roll label in the labeling machine work the entire process, including label delivery, positioning, out of the label, paste and backing paper re-roll, to successfully complete the labeling process, the overall label has the following requirements:

Label spacing: 3-4mm ± 0.2mm, the upper and lower edge of the label and the bottom of the backing paper spacing: 2mm

Surface material: basic grammage 78 g/m2 plus or minus 10%,Thickness: 0.064mm plus or minus 10%

Backing paper: Basic weight 61g/m2 plus or minus 10% Thickness: 0.055mm plus or minus 10%

Consistent release force, uniform thickness, a certain tensile strength, translucent Grassian base paper is generally between 60-80 g, fiber density tightness flatness to be good, not easy to break when labeling, the overall translucency to be consistent, the sensor correctly identify the location of the label.

Tensile force: machine direction: 16kg/25mm    Horizontal direction: 7kg/25mm

Tear resistance: machine direction: 25g / sheet    Crosswise: 31g/sheet


Before labeling to eliminate the static electricity in the roll label, so that the label is firm out of the label, from the backing paper, because static electricity will cause labeling when not out of the label or the labeling inaccuracy phenomenon, die-cutting to avoid cutting through the backing paper and not out of the label and torn backing paper phenomenon.


Product Description

The machine can be easily installed on the assembly line and packaging machine. Being independent controlled or linkage controlled, it is simply to realize automatic and unmanned labeling production;


Flexible application. Equipped with different labeling mechanisms, it can realize labeling on flat and uneven surfaces;


Easy adjustment structure. A single rod enable the header be flexibly adjusted with four degrees of freedom x and z, which can beflexibly matched to different pipelines;


High accuracy. The label tape deflection correction mechanism prevents the label from deviating. The subdivision stepping motor drives the label, and the front and rear positions of the label are accurate;



Intelligent control. automatic photoelectric tracking: no object, no labeling. Automatic correction and label detection to prevent missing labels and material waste;



Touch screen operation interface with full English annotations and fault prompt. Parameter settings are simple and quick.


Stable performance. Applying Panasonic PLC + Panasonic touch screen + subdivided stepping motor + optical fiber sensor electronic control system to support long-term machine running;


Optional functions: ①Hot coding/printing function; ② Base fine adjusting; ③Other functions (customized according to customer requirements).


Product Features

Machine detail

细节展示


Product Range Flexibility of Our Labeling Machines

可贴产品类型1_01

可贴产品类型1_02


Aftersales Service

1.    One-year machine warranty, lifetime maintenance service.

2.    Experienced engineers provide fast and professional 24 hours online guidance.

3.    Provide complete teaching videos and instruction manual, easy to operate and maintain. The video of the operation is stored on a USB shipped with the machine
